Adsorption dryer TROTEC® TTR 400

Product Number
CT1110000020
This adsorption dehumidifier achieves a dehumidification capacity of approx. 1.2 kg/h. It is lightweight, easy to handle and powerful and, among other things, versatile. TROTEC® TTR 400 offers professional quality “made in Germany”. Detail description

This adsorption dehumidifier achieves a dehumidification capacity of approx. 1.2 kg/h. It is lightweight, easy to handle and powerful and, among other things, versatile. TROTEC® TTR 400 offers professional quality "made in Germany". It is small, lightweight and surprisingly powerful thanks to its practical and optimised German industrial design. The infinitely variable air circulation control allows even smaller rooms requiring only minimal flow to reduce sound intensity and energy consumption. The filter can be removed simply by pulling it out, so no time-consuming screwing is required. This adsorption dehumidifier already complies with the EU Commission's Ecodesign requirements for motors No. 2009/640/EC implementing Directive 2005/32/EC of the European Parliament and of the Council. It is also known as the ErP 2015 (Energy-using Product Directive).

Features:

  • air quantity - stepless (continuous) adjustment
  • level-free air flow adjustment
  • quick and easy filter change
  • Extremely low maintenance and service requirements
  • suitable for installation in suspended ceilings
  • galvanized steel housing with powder paint
  • space-saving and stackable
  • light and handy
  • made of high quality components
  • practice-optimised German industrial design - protected industrial design
  • professional quality "Made in Germany"
  • connection to hygrostat
  • durable, robust and reliable

For more information about TROTEC® products, please visit www.trotec.com.

Manufacturer: TROTEC
Technical data: readings at 20 °C and 60 % relative humidity
Operating margin: 0 to 100% r.h. / -15 °C to +35 °C
Dehumidification performance: 1.2 kg/h
Airflow: 130 - 450 m³/h
Nominal air volume / external pressure: 350 m³/h at 150 Pa
Air regeneration / external pressure: 50 m³/h / 80 Pa
Connection for dry air Ø: 125 mm
Connection for humid air Ø: 80 mm
Electrical connection: 230V - 50/60 Hz - approx. 1.5 kW
Dimensions (L x W x H): 400 x 350 x 405 mm
Weight: 17 kg
