GRACO® Merkur Airmix Spraying Machine – for smaller painting jobs

Product Number

GG30C39

GG30C67

GG36C13

GG45C19

GG48C07

Choose a variant

Detailed description

The GRACO® Merkur Airmix air-powered high-pressure piston spraying machine is designed for smaller painting jobs on steel and wood structures. Air driven piston equipment using high pressure airmix spray technology, ensuring high spray quality, performance and low material loss. The performance of the device is suitable for smaller scale work or frequent shade changes. Can be used for a wide range of waterborne and solventborne materials.

Features:

robust two-wheel trolley in chrome finish
Input control unit for gun and pump control
maintenance-free air motor
full stainless steel piston pump
Flexible suction hose with pipe and filter
easy and quick cleaning, minimal loss of flushing agents
triple colour filtration
7.6 m x 1/4" material/air double hose
airmix Graco G40 high pressure spray gun - for the version with additional air
nozzle and nozzle AAM 415

For more information about GRACO® products, please visit www.graco.com.

Technical data

Manufacturer: Graco

Thread type of liquid inlet and outlet: NPT

Liquid inlet size: 3/4″

Liquid outlet size: 3/8″

Air inlet size: 1"

Filter: Integrated

Type of gun: G40

Maximum hose length: 7 m

Weight: 52 kg

Wetted material: stainless steel, tungsten carbide with 6% nickel, UHMWPE, PTFE, nylon, engineering plastic, fluoroelastomer

The package contains: pump and air controls, gun hose, suction hose, liquid filter

Typical applications: windows and doors, steel structures and parts, protection of wooden structures in construction, wooden furniture and parts

Compatible materials: primers and stains, thick-coat glazes, waterborne paints, acid-curing varnishes, polyurethanes, topcoats, epoxies

Variants

Product number	Variant
GG30C39	30:1 Airmix ratio, bottom pump capacity 25 cm3, max. liquid flow 1.5 l/min.
GG30C67	30:1 Airmix ratio, bottom pump capacity 75 cm3, max. fluid flow rate 4.5 l/min.
GG36C13	36:1 Airmix ratio, bottom pump capacity 100 cm3, max. liquid flow 6 l/min.
GG45C19	45:1 Airmix ratio, bottom pump capacity 50 cm3, max. liquid flow 3 l/min.
GG48C07	48:1 Airmix ratio, bottom pump capacity 75 cm3, max. fluid flow rate 4.5 l/min.
